Contact thermostats
THERMASREG® contact thermostats are installed directly on pipes or tanks to monitor, control and limit the temperature. Our devices are available as temperature controllers or temperature monitors.
-
THERMASREG® ALTR-060
1102-1040-1100-300
- Temperature controller (external setting)
- 0...+60 °C
- Tmin ± 5 K; Tmax ± 5 K
- Switching capacity (contact load):
16 (4) A; 24...250 V AC
at 24 V AC min. 150 mA - Switching differential: 8K (± 1K)
- Sensor element: bimetal
- Process connection:
by means of tension spring 220 mm, made of metal
(included in the scope of delivery) - IP40
$38.54
$45.76
-
THERMASREG® ALTR-060 U
1102-1040-2100-300
- Temperature monitor (internal setting)
- 0...+60 °C
- Tmin ± 5 K; Tmax ± 5 K
- Switching capacity (contact load):
16 (4) A; 24...250 V AC
at 24 V AC min. 150 mA - Switching differential: 8K (± 1K)
- Sensor element: bimetal
- Process connection:
by means of tension spring 220 mm, made of metal
(included in the scope of delivery) - IP40
$38.54
$45.76
-
THERMASREG® ALTR-090
1102-1040-1100-400
- Temperature controller (external setting)
- 0 ... 90 °C
- Tmin ± 5 K; Tmax ± 5 K
- Switching capacity (contact load):
16 (4) A; 24...250 V AC
at 24 V AC min. 150 mA - Switching differential: 8K (± 1K)
- Sensor element: bimetal
- Process connection:
by means of tension spring 220 mm, made of metal
(included in the scope of delivery) - IP40
$38.54
$45.76
-
THERMASREG® ALTR-090 U
1102-1040-2100-400
- Temperature monitor (internal setting)
- 0 ... 90 °C
- Tmin ± 5 K; Tmax ± 5 K
- Switching capacity (contact load):
16 (4) A; 24...250 V AC
at 24 V AC min. 150 mA - Switching differential: 8K (± 1K)
- Sensor element: bimetal
- Process connection:
by means of tension spring 220 mm, made of metal
(included in the scope of delivery) - IP40
$38.54
$45.76
-
THERMASREG® ALTR-1
1102-1030-1100-100
- Temperature controller (external setting)
- -35...+35 °C
- Tmin ± 5 K; Tmax ± 5 K
- Switching capacity (contact load):
24 ... 250 V AC + 10 %, 16 A, cos ϕ = 1.0
24 ... 250 V AC + 10 %, 1.5 A, cos ϕ = 0.6
at 24 V AC min. 150 mA - Switching differential: 5K (± 1K)
- Endless voltage in metal turnbuckle
(included in the scope of delivery) - IP65
$121.87
$144.86
-
THERMASREG® ALTR-3
1102-1030-1100-300
- Temperature controller (external setting)
- 0...+60 °C
- Tmin ± 5 K; Tmax ± 5 K
- Switching capacity (contact load):
24 ... 250 V AC + 10 %, 16 A, cos ϕ = 1.0
24 ... 250 V AC + 10 %, 1.5 A, cos ϕ = 0.6
at 24 V AC min. 150 mA - Switching differential: 5K (± 1K)
- Endless voltage in metal turnbuckle
(included in the scope of delivery) - IP65
$121.87
$144.86
-
THERMASREG® ALTR-5
1102-1030-1100-400
- Temperature controller (external setting)
- 0 ... 90 °C
- Tmin ± 5 K; Tmax ± 5 K
- Switching capacity (contact load):
24 ... 250 V AC + 10 %, 16 A, cos ϕ = 1.0
24 ... 250 V AC + 10 %, 1.5 A, cos ϕ = 0.6
at 24 V AC min. 150 mA - Switching differential: 5K (± 1K)
- Endless voltage in metal turnbuckle
(included in the scope of delivery) - IP65
$121.87
$144.86
-
THERMASREG® ALTR-7
1102-1030-1100-500
- Temperature controller (external setting)
- 0...120 °C
- Tmin ± 5 K; Tmax ± 5 K
- Switching capacity (contact load):
24 ... 250 V AC + 10 %, 16 A, cos ϕ = 1.0
24 ... 250 V AC + 10 %, 1.5 A, cos ϕ = 0.6
at 24 V AC min. 150 mA - Switching differential: 5K (± 1K)
- Endless voltage in metal turnbuckle
(included in the scope of delivery) - IP65
$121.87
$144.86
-
THERMASREG® ALTR-1 U
1102-1030-2100-100
- Temperature monitor (internal setting)
- -35...+35 °C
- Tmin ± 5 K; Tmax ± 5 K
- Switching capacity (contact load):
24 ... 250 V AC + 10 %, 16 A, cos ϕ = 1.0
24 ... 250 V AC + 10 %, 1.5 A, cos ϕ = 0.6
at 24 V AC min. 150 mA - Switching differential: 5K (± 1K)
- Endless voltage in metal turnbuckle
(included in the scope of delivery) - IP65
$133.94
$159.21
-
THERMASREG® ALTR-3 U
1102-1030-2100-300
- Temperature monitor (internal setting)
- 0...+60 °C
- Tmin ± 5 K; Tmax ± 5 K
- Switching capacity (contact load):
24 ... 250 V AC + 10 %, 16 A, cos ϕ = 1.0
24 ... 250 V AC + 10 %, 1.5 A, cos ϕ = 0.6
at 24 V AC min. 150 mA - Switching differential: 5K (± 1K)
- Endless voltage in metal turnbuckle
(included in the scope of delivery) - IP65
$133.94
$159.21
-
THERMASREG® ALTR-5 U
1102-1030-2100-400
- Temperature monitor (internal setting)
- 0 ... 90 °C
- Tmin ± 5 K; Tmax ± 5 K
- Switching capacity (contact load):
24 ... 250 V AC + 10 %, 16 A, cos ϕ = 1.0
24 ... 250 V AC + 10 %, 1.5 A, cos ϕ = 0.6
at 24 V AC min. 150 mA - Switching differential: 5K (± 1K)
- Endless voltage in metal turnbuckle
(included in the scope of delivery) - IP65
$133.94
$159.21
-
THERMASREG® ALTR-7 U
1102-1030-2100-500
- Temperature monitor (internal setting)
- 0...120 °C
- Tmin ± 5 K; Tmax ± 5 K
- Switching capacity (contact load):
24 ... 250 V AC + 10 %, 16 A, cos ϕ = 1.0
24 ... 250 V AC + 10 %, 1.5 A, cos ϕ = 0.6
at 24 V AC min. 150 mA - Switching differential: 5K (± 1K)
- Endless voltage in metal turnbuckle
(included in the scope of delivery) - IP65
$133.94
$159.21
We also manufacture individually
Do you have special requirements?As a manufacturer with our own production facilities in Germany, we are always in a position to produce products outside the standard range.
